66-77 Bronco Front Winch Bumper | RockSolid Series (PF301)
66-77 Bronco Front Winch Bumper | RockSolid Series (PF301)
This classy early bronco bumper offers full front end and fender protection with great approach angles. It is made from ¼” plate steel, it's winch ready and is an easy bolt on installation.
The RockSolid™ Bumper design makes it difficult for obstacles to trap. It is designed so that your truck slides upwards and onwards over any obstacle rather than catching. This very durable and modern design has multiple built in tow points or add a set of ‘D’ ring tabs for the ultimate tow points. >This bumper will fit almost any winch so long as it uses the standard mounting bolt pattern which is 10" x 4.5".
Easy bolt-on installation with no welding required however you will need to drill four 7/16" holes IN YOUR BUMPER to install, so please test fit the bumper to the truck before you apply paint or powder coat so that you can drill the appropriate hole. You will use the holes in the front of your Bronco Frame as the mark for where the holes should be drilled. Drill a hole in the top and bottom of each side of the bumper frame mount.
*This statement applied to the fully Welded edition of our bumper. The other editions require several hours of welding and grinding.
Edition
| Box Kit: Completely disassembled bumper kit shipped in a box. Only recommended for experienced welders/fabricators as it requires several hours of welding and grinding to complete. The lead time for this product is significantly less. (Typically a 3-4 week lead time) |
| Tack Kit: A tack welded kit that arrives in its true form and will require several hours of welding and grinding to complete. It is not a flat kit and will not be more economical when shipping. |
| Welded: Arrives as unfinished raw-steel ready to install. We ALWAYS recommend test fitting the bumper to your truck BEFORE applying paint or powder coat. Once you have successfully mounted the bumper to your truck, it is safe to remove it and apply a finish. |
Add-On's
Push Bar: Add a push bar to your front bumper.
| The Flat Top (No Bar): Just like it sounds. This option means there is no push bar. |
| The Bull Bar: A single low-cut hoop in the center of the bumper made from 2" 0.120 wall round tubing. |
| The Pre-Runner: A taller center hoop with diagonal kicker tubes extending to the outside edges of the bumper. Made from 2" 0.120 wall round tubing and 1 1/4" side braces. |
Note: This bumper is not offered with a body lift option. You can still run this bumper if you have a body lift, the extra spacers are not needed due to the engineering of the bumper.
